Extech HD500 Psychrometer with InfraRed Thermometer Kit

The HD500 can be used to carry out measurements of humidity and temperature.

Designed for quick and easy evaluations, the Extech HD500 includes a built-in probe that can be used to measure the overall ambient temperature and humidity of the air. This probe allows the tester to measure RH from 0 to 100% and air temperature from 14 to 140°F (-10 to 60°C). It can also be used to calculate dew point (-90.4 to 140°F (-68 to 60°C) and wet bulb (-6.88 to 140°F (-21.6 to 60°C).

The HD500 also features a built in port that allows the insertion of a Type K temperature probe. Once equipped this enables the HD500 to be used for contact-based temperature measurement across a wide measurement range of -148 to 2501°F (-100 to 1372°C).

If it isn't possible to get close to the area where a temperature measurement needs to take place the HD500 also inclues a 30:1 ratio infrared thermometer that can carry out completely non-contact measurements of temperature between a range of -58 to 932°F (-50 to 500°C).

The HD500 also includes a USB port for connecting to PC and will shut down when left idle for a period of time.

Extech HD500 Psychrometer with Infrared Thermometer Key Features

  • 3-in-1 combination testing device includes humidity meter, type K thermometer and infrared thermometer
  • Infrared thermometer includes distance to target ratio of 30:1 and measurement of temperature -58 to 932°F (-50 to 500°C)
  • Type K temperature function: -148 to 2501°F (-100 to 1372°C)
  • High accuracy relative humidity measurements from 0 to 100% RH
  • Heavy duty rugged double moulded housing
  • Large backlit triple LCD screen
  • USB port
  • Auto power off
  • Dew point and wet bulb calculation
  • Air temperature calculation

What's Included?

  • Extech HD500 Psychrometer with Infrared Thermometer
  • Windows Compatible Software with USB Cable
  • Type K Bead Wire Temperature Probe
  • Built-In Stand
  • Hard Carrying Case
  • 9V Battery
